Hinge joint field fence manufactured with 2Life® wire which lasts at least two times longer than heavily galvanised wire.

  • A conventional hinge joint field fence manufactured to
  • BS EN 10223-5.
  • Designed for ease of pull up when erecting.
  • Suitable for the permanent fencing of livestock – sheep, cattle, pigs etc.
  • A centreless core to provide a snag free, easily rolled out fence where all of the roll can be used.
  • A deep crimp between the verticals to aid tensioning over uneven ground, elasticity against livestock and different weather conditions and to allow rainwater to drain away from the joint.
  • Different widths to suit your fencing needs: 150 mm – 6” gap for strength and rigidity; 300 mm – 12” gap to prevent damage and injury to livestock; 225 mm – 9” for lamb safe fencing.
  • Also available with factory fitted Gripples® on all line wires.
Designation Height Vertical Spacing Length Nominal Weight Rolls/pallet
C6 90 30

C6 90 30

900mm 300mm 50/100m 21/42kg 20/16
C7 10 15

C7 10 15

1030mm 150mm 50m 31kg 20
C8 80 15

C8 80 15

800mm 150mm 50/100/250m 32/64/160kg 20/12/5
C8 80 22

C8 80 22

800mm 225mm 50/100m 27/54 20/16
C8 80 30

C8 80 30

800mm 300mm 50m 25kg 20
C8 90 15

C8 90 15

900mm 150mm 50m 33kg 20
C8 11 30

C8 11 30

1145mm 300mm 50m 26kg 20
C9 10 15

C9 10 15

1000mm 150mm 50m 36kg 20
C10 12 15

C10 12 15

1180mm 150mm 50m 41kg 20

Other patterns, sizes and lengths can be made on request.

Request a call back about this product

Product Highlights

Mesh

Profile

  • Top & bottom wires Ø 3.00 mm
    Min 600 N/mm2
  • Horizontal wires Ø 2.50 mm
    Min 600 N/mm2
  • Vertical wires Ø 2.50 mm
    Min 350 N/mm2

Coating Technology

Guarantee

2Life® lasts at least 2 times longer than heavily galvanised wire BS EN 10244-2 Class A.

Roll Length

Up to 250m

Centreless core providing snag free, easily to roll out fence where all of the roll can be used.

Suitable for the following applications:
